Deep dive into Lambda event-filters for DyanmoDB

Deep dive into Lambda event-filters for DyanmoDB

Jones Zachariah Noel N's photo
Jones Zachariah Noel N
ยทDec 12, 2021ยท

5 min read

Play this article

Amazon Lambda Functions with the event-filtering for DynamoDB Streams enables ease of integration and application development.

There are a couple of good blog posts with talks about how to setup triggers with filter patterns to your Lambda fns.

To know about what is DynamoDB Streams and it's use-cases - {%post aws-builders/using-dynamodb-streams-and-lambda-in-your-serverless-applications-3epl%} To know about what is the announcement of Lambda functions Event-filtering - {%post aws-builders/trigger-lambda-functions-with-event-filtering-2pnb%} To know about DynamoDB Streams which are helpful with event-filtering - {%post aws-builders/new-dynamodb-streams-filtering-in-serverless-framework-3lc5%} {%post nosqlknowhow/aws-lambda-event-filter-of-amazon-dynamodb-streams-16pc%} {%post aws-builders/filtering-dynamodb-streams-before-lambda-p5p%}

Key takeaways

In this blog post, we will deep dive into the feature itself and we will learn about -

How the filtering works

The filter expression or the filter pattern JSON uses a strict JSON format which is used to match the filtering criteria. For a DynamoDB Stream based event, the JSON is validated against the key dynamodb which is part of the event JSON.

{
    "Records": [
        {
            ...
            "dynamodb": { }
            ...
        }
    ]
}

Flow diagram Whenever an action on DynamoDB putItem or updateItem or deleteItem occurs, the INSERT or MODIFY or REMOVE events are triggered respectively if DynamoDB Streams are enabled. This helps handling the needed business logic for specific actions. Now with event filtering with patterns are available, this performs additional validation before the Lambda function is invoked. The flow diagram explains, whenever there is a DynamoDB Stream invoked, it checks if the target Lambda fn has any event filtering pattern defined or not. If the pattern is available, event JSON is validated against it and if the event JSON matches the criteria then the Lambda fn gets invoked. If nothing is matched, the event is discarded. If the pattern itself is not defined, the Lambda function gets invoked as event-filter patterns are optional.

Event which is triggered whenever a DynamoDB INSERT operation happens is -

{
    "Records": [
        {
            "eventID": "42a3c355ea58b7c68a96368be0f8fa68",
            "eventName": "INSERT",
            "eventVersion": "1.1",
            "eventSource": "aws:dynamodb",
            "awsRegion": "us-east-1",
            "dynamodb": {
                "ApproximateCreationDateTime": 1638968744,
                "Keys": {
                    "sk": {
                        "S": "CAR"
                    },
                    "pk": {
                        "S": "USA3271395584644fordgalaxie5001972-01-01"
                    }
                },
                "NewImage": {
                    "miles_per_gallon": {
                        "N": "14"
                    },
                    "acceleration": {
                        "N": "13"
                    },
                    "car_name": {
                        "S": "Ford Galaxie 500"
                    },
                    "horsepower": {
                        "N": "153"
                    },
                    "year": {
                        "S": "1972-02-01"
                    },
                    "origin": {
                        "S": "USA"
                    },
                    "sk": {
                        "S": "CAR"
                    },
                    "displacement": {
                        "N": "351"
                    },
                    "pk": {
                        "S": "USA3271395584644fordgalaxie5001972-01-01"
                    },
                    "cylinders": {
                        "N": "8"
                    },
                    "weight_in_lbs": {
                        "N": "4129"
                    }
                },
                "SequenceNumber": "530563900000000048422878623",
                "SizeBytes": 228,
                "StreamViewType": "NEW_AND_OLD_IMAGES"
            },
            "eventSourceARN": "arn:aws:dynamodb:us-east-1:xxxxxxx:table/cars-demo/stream/2021-11-28T18:05:10.127"
        }
    ]
}

Filter patterns supported

The event filtering uses JSON based patterns which are capable with the following criteria checks -

CriteriaExampleSyntax
Nullorigin is null"origin": [ null ]
Emptyorigin is empty"origin": [""]
Equalsorigin is "USA""origin": ["USA"]
Andorigin is "USA" and cylinders is 8"origin": ["USA"], "cylinders": ["8"]
Ororigin is "USA" or "Germany""origin": ["USA","Germany"]
Notorigin is not Japan"origin": { "anything-but": [ "Japan" ] }
Existsdisplacement exists"displacement ": [ { "exists": true } ]
Does not existsdisplacement does not exists"displacement ": [ { "exists": false} ]
Begins withpk begins with "USA""pk": [ {"prefix": "USA" } ]

Limitations with event-filtering

  • The max number of event-filtering patterns that can be defined for a Lambda fn is 5. Additionally, you cannot have multiple event sources from the same DynamoDB table.
  • Each of the 5 patterns is validated against an OR condition i.e. pattern1 OR pattern2 OR pattern3 OR pattern4 OR pattern5
  • Numeric comparisons such as numeric equals or number in range cannot be performed as the DynamoDB Streams uses the marshalled JSON structure which has numbers also as strings.
    "horsepower": {
       "N": "153"
    },

  • A individual pattern criteria can validate with an AND condition only. Eg. "origin": ["USA","Germany"], "cylinders": ["8"], "pk": [ {"prefix": "USA" } ] would validate when "origin" is either "USA" or "Germany" and "cylinders" is 8 and "year" begins with "1972".

Use-cases and it's associated filter-patterns

Whenever you would want the Lambda function to be invoked only if -

  • Have atleast one cylinder.
    {
    "filters": [
      {
        "pattern": "{\"dynamodb\" : \"{ \"NewImage\" : \"cylinder\" : \"N\" :  { \"anything-but\": [ \"0\" ] } }\" }"
      }
    ]
    }

  • A new car is added to the DynamoDB table.
    {
    "filters": [
      {
        "pattern": "{\"eventName\" : [\"INSERT\"], \"dynamodb\" : \"{ \"Key\" : \"sk\" : \"S\" :  [\"CAR\"] }\"  }"
      }
    ]
    }

  • A car from USA origin is modified.
    {
    "filters": [
      {
        "pattern": "{\"eventName\" : [\"MODIFY\"], \"dynamodb\" : \"{ \"NewImage\" : \"origin\" : \"S\" :  [\"USA\"] }\"  }"
      }
    ]
    }

  • A car name beginning with "Ford" is deleted.
    {
    "filters": [
      {
        "pattern": "{\"eventName\" : [\"REMOVE\"], \"dynamodb\" : \"{ \"OldImage\" : \"car_name\" : \"S\" :  [{\"prefix\": \"Ford\" }] }\"  }"
      }
    ]
    }

  • Either if a new car is added or removed.
    {
    "filters": [
      {
        "pattern": "{\"eventName\" : [\"INSERT\",\"REMOVE\"], \"dynamodb\" : \"{ \"Key\" : \"sk\" : \"S\" :  [\"CAR\"] }\"  }"
      }
    ]
    }

  • Either if a new car is added or if the any car with year 1971 is added / deleted / updated.
    {
    "filters": [
      {
        "pattern": "{\"eventName\" : [\"INSERT\"]}"
      },
      {
        "pattern": "{\"dynamodb\" : \"{ \"OldImage\" : \"year\" : \"S\" :  [{\"prefix\": \"1971\" }] }\"  }"
      }
    ]
    }


Conclusion

The event-filtering with DynamoDB Streams helps in filtering out and focusing only on the pattern of data which needs the Lambda function to be invoked. This helps in efficient and optimized Lambda function code as the additional code to validate various conditions. This also adheres to the new Well Architected Model's new pillar Sustainability pillar which ensures there is less carbon foot-print because of limited Lambda function executions.
